HY610 1kg  Gold Thermal Grease in the Can
HY610 1kg  Gold Thermal Grease in the Can
HY610 1kg  Gold Thermal Grease in the Can
HY610 1kg  Gold Thermal Grease in the Can
HY610 1kg  Gold Thermal Grease in the Can
>

HY610 1kg Gold Thermal Grease in the Can

HY610 Gold Thermal Grease is Special product for CPU DIYers,...

  • Model:HY610-CN1000
  • Brand:HALNZIYE
  • Colour:Gold
  • Thermal conductivity:3.05 w/m-k
  • Package:1KG in the Can
  • Application:CPU, GPU etc.
  • Thermal Impedance:0.018 °C-in2/W
  • Concentration:350 ± 10 1/10mm
  • High temperature resistance:-30 ~ 220 °C
  • Operation temperature:-20 ~ 180 °C
Order Hotline:+86-0755-28772795

product details

HY610 Gold Themral Grease



Product Description



HY610 Gold Thermal Grease, Special for DIYers, Thermal grease passed SGS, ROHS, SVHC Certificates, differen packing for your different demands.



Thermal conductivity: 3.05 w/m-k

Good Electric Insulating, Breakdown 1kv voltage

Low Thermal Impedance, keep grease condition with long time

With a wide range working temperature, keep stable performance at temperature

-20 ℃ ~180 ℃

High performance, saving your cost.



Specifications:



ModelHY610Unit
ColorGoldNo
Thermal Conductivity3.05W/m-k
Thermal Impedance<0.073℃-in²/W
Specific Gravity>2.33g/cm³
Thixotropic Index350±101/10mm
Moment Bore Temperature-30~220

Operation

Temperature

-20~180



Ingredients



Silicone Compounds20%
Carbon Compounds20%
Metal Oxide Compound60%



Product Applications



High thermal Demand module

Cooling device to the end plate or between the Frame

Automotive Engine Control

Computer CPU

Power conversion apparatus

Notebook and desktop computers

Network communications equipment

Household appliances ,electronic components ,electrical etc.


Application Method



1. Clean the CPU and heat sink surface, wipe the surface lightly with a cotton ball or cotton seab dampened with our thermal cleanser.

2. Place a tiny drop of thermal grease to the center of the cooler base, smear it evenly with scraper, best thickness is 0.13~0.15mm.

3. Attach the heat sink to the processor and avoid removing the heat sink after installing it.
4. Finished


Product Storage



Room temperature
