Thermal grease can be used in the power supply industry, such as power adapters, power modules, etc., to improve the heat dissipation efficiency of power equipment and extend its service life.
The use of thermal silicone in the power supply industry:
First, the power supply can be divided into the following categories according to different standards:
1, according to the use of power size can be divided into large power supply and small power supply;
2, according to the application of the scene is roughly divided into: adapter, UPS power supply, PC power supply, switching power supply, communication power supply, power rectifier, LED driver lighting power supply;
3, according to the internal structure promotion process is divided into: AT power supply, ATX power supply, Micro ATX power supply.
Second, the main use of thermal silicone in the power supply:
1, the main chip of the power supply: can be divided according to the power of the power chip, the main chip of the large power supply will generally have high requirements, such as UPS power supply, because of its strong power supply function, the main chip to bear the working intensity of the whole body, at this time will collect a lot of heat, then we need to heat conduction material as an outstanding heat conduction medium.
2, the mold wire tube: the mold wire tube is in addition to the main chip of the power supply, the heat of the larger components, the use of more types of thermal conductive materials, such as: thermal silicon tape, thermal grease and other materials.
3, transformer: transformer is the energy conversion of things, shouldering the conversion of voltage, current and resistance, but because of the special performance of the transformer, the use of thermal conductivity materials will also have special needs.
4, heat dissipation module and PDP TV heat dissipation module, power industry heat dissipation module: located on the chip and heat source that need heat dissipation, connect the radiator or structural heat dissipation. The material characteristics of the thermal conductive silicone sheet determine that it has an outstanding filling effect, especially the use of a certain amount of shrinkage can make the thermal resistance smaller, better thermal conductivity, and the material itself has an outstanding electrical insulation effect and shock absorption effect, which is different from other thermal conductive media materials.
In short, thermal grease has a wide range of applications in industrial production, which can improve the heat dissipation efficiency of equipment, extend its service life, and also ensure the stability and reliability of electronic components.
